Packet Tracer Simulation – TCP and UDP Communications

Part 1: Generate Network Traffic in Simulation Mode
Step 1: Generate traffic to populate Address Resolution Protocol (ARP) tables.
  • Click MultiServer and click the Desktop tab > Command Prompt.
  • Enter the ping 192.168.1.255 command. This will take a few seconds as every device on the network responds to MultiServer.
  • Close the MultiServer window.
Step 2: Generate web (HTTP) traffic.
  • Switch to Simulation mode.
  • Click HTTP Client and click the Desktop tab > Web Browser.
  • In the URL field, enter 192.168.1.254 and click Go. Envelopes (PDUs) will appear in the simulation window.
  • Minimize, but do not close, the HTTP Client configuration window.
Step 3: Generate FTP traffic.
  • Click FTP Client and click the Desktop tab > Command Prompt.
  • Enter the ftp 192.168.1.254 command. PDUs will appear in the simulation window.
  • Minimize, but do not close, the FTP Client configuration window.
Step 4: Generate DNS traffic.
  • Click DNS Client and click the Desktop tab > Command Prompt.
  • Enter the nslookup multiserver.pt.ptu command. A PDU will appear in the simulation window.
  • Minimize, but do not close, the DNS Client configuration window.
Step 5: Generate Email traffic.
  • Click E-Mail Client and click the Desktop tab > E Mail tool.
  • Click Compose and enter the following information:
    • 1)  To: user@multiserver.pt.ptu
    • 2)  Subject: Personalize the subject line
    • 3)  E-Mail Body: Personalize the Email
  • Click Send.
  • Minimize, but do not close, the E-Mail Client configuration window.
Step 6: Verify that the traffic is generated and ready for simulation.
Every client computer should have PDUs listed in the Simulation Panel.
Part 2: Examine Functionality of the TCP and UDP Protocols
Step 1: Examine multiplexing as all of the traffic crosses the network.
You will now use the Capture/Forward button and the Back button in the Simulation Panel.
  • Click Capture/Forward once. All of the PDUs are transferred to the switch.
  • Click Capture/Forward again. Some of the PDUs disappear. What do you think happened to them?
  • Click Capture/Forward six times. All clients should have received a reply. Note that only one PDU can cross a wire in each direction at any given time. What is this called?
  • A variety of PDUs appears in the event list in the upper right pane of the simulation window. Why are they so many different colors?
  • Click Back eight times. This should reset the simulation.
Step 2: Examine HTTP traffic as the clients communicate with the server.
  • Filter the traffic that is currently displayed to display only HTTP and TCP PDUs filter the traffic that is currently displayed:
  • 1)  Click Edit Filters and toggle the Show All/None check box.
  • 2)  Select HTTP and TCP. Click anywhere outside of the Edit Filters box to hide it. The Visible Events should now display only HTTP and TCP PDUs.
  • Click Capture/Forward. Hold your mouse above each PDU until you find one that originates from HTTP Client. Click the PDU envelope to open it.
  • Click the Inbound PDU Details tab and scroll down to the last section. What is the section labeled? Are these communications considered to be reliable?
  • Record the SRC PORT, DEST PORT, SEQUENCE NUM, and ACK NUM values. What is written in the field to the left of the WINDOW field?
  • Close the PDU and click Capture/Forward until a PDU returns to the HTTP Client with a checkmark.
  • Click the PDU envelope and select Inbound PDU Details. How are the port and sequence numbers

different than before?
  • There is a second PDU of a different color, which HTTP Client has prepared to send to MultiServer. This is the beginning of the HTTP communication. Click this second PDU envelope and select Outbound PDU Details.
  • What information is now listed in the TCP section? How are the port and sequence numbers different from the previous two PDUs?
  • Click Back until the simulation is reset.
Step 3: Examine FTP traffic as the clients communicate with the server.
  • In the Simulation Panel, change Edit Filters to display only FTP and TCP.
  • Click Capture/Forward. Hold your cursor above each PDU until you find one that originates from FTP Client. Click that PDU envelope to open it.
  • Click the Inbound PDU Details tab and scroll down to the last section. What is the section labeled?
Are these communications considered to be reliable?
  • Record the SRC PORT, DEST PORT, SEQUENCE NUM, and ACK NUM values. What is written in the field to the left of the WINDOW field?
  • Close the PDU and click Capture/Forward until a PDU returns to the FTP Client with a checkmark.
  • Click the PDU envelope and select Inbound PDU Details. How are the port and sequence numbers different than before?
  • Click the Outbound PDU Details tab. How are the port and sequence numbers different from the previous two results?
  • Close the PDU and click Capture/Forward until a second PDU returns to the FTP Client. The PDU is a different color.
  • Open the PDU and select Inbound PDU Details. Scroll down past the TCP section. What is the message from the server?
  • Click Back until the simulation is reset.
Step 4: Examine DNS traffic as the clients communicate with the server.
  • In the Simulation Panel, change Edit Filters to display only DNS and UDP.
  • Click the PDU envelope to open it.
  • Click the Inbound PDU Details tab and scroll down to the last section. What is the section labeled?

Are these communications considered to be reliable?
  • Record the SRC PORT and DEST PORT values. Why is there no sequence and acknowledgement number?
  • Close the PDU and click Capture/Forward until a PDU returns to the DNS Client with a checkmark.
  • Click the PDU envelope and select Inbound PDU Details. How are the port and sequence numbers

different than before?
  • What is the last section of the PDU called?
  • Click Back until the simulation is reset.
Step 5: Examine email traffic as the clients communicate with the server.
  • In the Simulation Panel, change Edit Filters to display only POP3, SMTP and TCP.
  • Click Capture/Forward. Hold your cursor above each PDU until you find one that originates from E-mail
    Client. Click that PDU envelope to open it.
  • Click the Inbound PDU Details tab and scroll down to the last section. What transport layer protocol does
    email traffic use?

Are these communications considered to be reliable?
  • Record the SRC PORT, DEST PORT, SEQUENCE NUM, and ACK NUM values. What is written in the field to the left of the WINDOW field?
  • Close the PDU and click Capture/Forward until a PDU returns to the E-Mail Client with a checkmark.
  • Click the PDU envelope and select Inbound PDU Details. How are the port and sequence numbers
different than before?
  • Click the Outbound PDU Details tab. How are the port and sequence numbers different from the previous two results?
  • There is a second PDU of a different color that HTTP Client has prepared to send to MultiServer. This is the beginning of the email communication. Click this second PDU envelope and select Outbound PDU Details.
  • How are the port and sequence numbers different from the previous two PDUs?
  • What email protocol is associated with TCP port 25? What protocol is associated with TCP port 110?
  • Click Back until the simulation is reset.
Step 6: Examine the use of port numbers from the server.
  • To see TCP active sessions, perform the following steps in quick succession:
  • 1)  Switch back to Realtime mode.
  • 2)  Click MultiServer and click the Desktop tab > Command Prompt.
